Camber

MT15/MR15
Select Your Size
Select Center Profile
Description

Cones, Corners, or Car Shows, We’ve Got You Covered……

  • Concave Shallow Center Profile – Big brake clearance with a semi-flat concave center. Available in 18”,19”, 20”, 22”, & 24"
  • Concave Deep Center Profile – For a maximum concave profile. Available in 18”,19”, 20”, 22”, & 24" in widths 10” and wider.



CONCAVE SHALLOW



CONCAVE DEEP

1-3/4" Caliper Clearance  1-5/8" Caliper Clearance
SizeMin Backspace Max Backspace
 SizeMin Backspace Max Backspace
18x73.254.375  18x102.756.625
18x83.255.375  18x112.757.625
18x93.256.375  18x122.758.625
18x103.257.375  19x102.756.625
18x113.258.375  19x112.757.625
18x123.259.375  19x122.758.625
19x83.255.375  20x102.756.375
19x93.256.375  20x10.52.757.125
19x103.257.375  20x122.758.625
19x113.258.375  20x152.7511.625
19x123.259.375  22x102.756.625
20x8.53.255.875  22x10.52.757.125
20x93.256.375  22x122.758.625
20x103.257.375
20x10.53.257.875
20x123.259.375
20x153.2512.375
22x8.53.255.875
22x93.256.375
22x103.257.375
22x10.53.257.875
22x123.259.375


Finish Options




Description
Center(ea)
Rim(ea)
Solid ColorStandard$ 100.00
Polished$ 200.00Standard
Brushed with Clear$ 100.00$ 125.00
Polished with Clear$ 225.00Not Available
Brushed with Transparent Color$ 125.00$ 125.00
Polished with Transparent Color$ 250.00$ 125.00
Brushed/Polished with Clear$ 250.00Not Available
Brushed/Polished with Transparent Color$ 300.00Not Available
Available powder coat options for Pro-Touring wheels are listed below.


Forging Profiles

Pro_Touring_Concave_Shallow_WCTF_-_Cross_Section

Concave Shallow
Big Brake Clearance with a semi-flat Concave Center



Pro_Touring_Concave_Deep_WCTD_-_Cross_Section

Concave Deep
For a maximum concave profile
