- Available in 17”, 18" and 20" diameter
- Also available in single bead lock
- Accept standard conical seat lug nuts
Redline Race Wheels Features:
- Forged 6061 t6 centers for superior strength and weight
- 1pc spun 6061 barrels for ultimate run out and weight savings
- Machined serrations at the bead seat for improved tire-to-rim grip reducing tire spin.
| 17" REDLINE |
| Wheel Size | Minimum Backspace | Maximum Backspace |
| 17x5 | 2.50 | 2.625 |
| 17x6 | 3.25 | 3.50 |
| 17x7 | 3.25 | 4.50 |
| 17x8 | 3.25 | 5.50 |
| 17x9.5 | 3.25 | 7.00 |
| 17x10 | 3.25 | 7.50 |
| 17x11 | 3.25 | 8.50 |
| 18" REDLINE |
| Wheel Size | Minimum Backspace | Maximum Backspace |
| 18x5 | 2.50 | 2.65 |
| 18x6 | 3.25 | 3.50 |
| 18x7 | 3.25 | 4.50 |
| 18x8 | 3.25 | 5.50 |
| 18x9 | 3.25 | 6.50 |
| 18x9.5 | 3.25 | 7.00 |
| 18x10 | 3.25 | 7.50 |
| 18x11 | 3.25 | 8.50 |
| 18x12 | 3.25 | 8.50 |
| 20" REDLINE |
| Wheel Size | Minimum Backspace | Maximum Backspace |
| 20x7 | 3.25 | 4.50 |
| 20x8 | 3.25 | 5.50 |
| 20x9 | 3.25 | 6.50 |
| 20x9.5 | 3.25 | 7.00 |
| 20x10 | 3.25 | 7.50 |
| 20x11 | 3.25 | 8.50 |
| 20x12 | 3.25 | 8.50 |
Solid Custom Finish Options
Polished Transparent Custom Finish Options
